iCharger DX6 2 x 6S / 2x900W

With the new iCharger DX6, the renowned manufacturer Junsi has launched a DUO charger in a compact format. The new DX6 charger combines the advantages of the well-known Junsi iCharger 406DUO with the portability of a small pocket charger. Despite the small dimensions of 92 x 112 x 40 mm, no compromises were made in terms of performance and usability. The newly developed rotary wheel has a very good pressure point and makes operation much easier. The technical data is impressive, 1500W charging power (from >25V), 1-6s LiXx cells and up to 32Ampere charging current are also sufficient for large batteries with high capacity. Of course, all other battery types such as LiHV, LiIo, NiZn, PB, NiCd or NiMh batteries can also be charged. The discharge power is 60 watts in total (40 watts per output if only one output is used), but can be increased to up to 1600 watts using an external load (discharge resistor). Of course, the iCharger DX6 also masters regenerative charging. Here, the battery capacity is fed back into the supply battery, for example, from a full flight battery. The balancer current of 4 amps in total (2A per output) always ensures perfectly balanced cell voltages. A USB-C PD port for charging smartphones etc (5V/3A, 9V/2A, 12V/1.5A) or for software updates is also installed. The micro SD slot can be used to log the data, but also for future updates. A servo tester is also integrated, please note that an external power supply is required! The menu navigation is almost identical to the well-known Junsi iCharger 308DUO, 406 DUO or 4010DUO. A 2.4" IPS LCD display ensures good legibility even in low light. Instructions in English are included with the loader in the form of a CD; you can download the German version from us. All Junsi chargers of the X and DUO series have been developed and approved for use in model construction. Industrial use is not intended and therefore not permitted! All Junsi chargers may only be operated with power packs developed for model making! No AGM batteries may be charged in the PB program!

Technical data:

• Charging current adjustable per output: 0.1-32A
• Charging current adjustable in synchronous mode: 0.1-50A
• Max. Number of NiCd/NiMH batteries: 1-15
• Max. Power: 1500W
• Charging power max syncron: 1500W
• External high-current discharge synchronous: 1600W
• Max. Lead-acid battery voltage: 24V
• Balancer Equalizing current per output: 2A
• Discharge current adjustable for feedback: 32A
• Discharge power per output: 40W
• Balancer Compensation current synchronous mode: 4A
• Max. charging current: 50A
• Max. number of LiPo cells: 6
• Max. number of LiHv cells: 6
• Max. Discharge power: 60W
• Discharge power max. in synchronous mode: 60W
• Input current limit: 65A
• Input voltage: 9-34VDC
• External high-current discharge asynchronous : 900W
• Max. charging power at one output: 900W
• Length (mm): 92
• Micro SD card slot: Yes
•  Integrated power supply: No
• Charging output connector type: XT60
• Input connector type: XT90

Scope of delivery:

• Junsi iCharger DX6
